Resistors in PHEMT RF Switch ? ?
时间：04-07
整理：3721RD
点击：
In the RF swithch circuit, many large resistors (>10 kohm) are connected in serese with Gate of the FET, and shunt with source and drain. What is the functionality of these resistors? thanks.
nobody answer?
They are used for DC Polarization to improve the speed.
